Lowrance Eagle 9 Fish Finder
Large Screen Fish Finder with Chartplotter
With a large and bright 9in screen, the Eagle 9 shows you sonar and mapping data in crisp colour so that you can easily find fish and structure. Easy-to-use with autotuning sonar and FishReveal technology. Choose from the HDI transducer with deepwater performance or side-scanning Tripleshot transducer options.
Eagle 9 with 50/200 HDI Transducer: £676.99
Eagle 9 with Tripleshot HD Transducer: £728.99
Lowrance Eagle 9 Fish Finder
- More Info
- Features
- Mounting Options
- Transducer Installation
- Power Options
- Delivery
Lowrance Eagle 9 Fish Finder
The perfect companion for large kayaks and small boats, the Eagle 9 offers a large screen fish finder and chartplotter with easy to use functionality. Choose from two transducer types - the HDI transducer for clear sonar readings below your craft, or the Tripleshot HD transducer for additional side scanning sonar for views either side of your craft too. Designed for those wanting the latest fish finding features in an easy to use device. Fish Reveal technology takes both CHIRP and Downscan Imaging readings and combines these into an easy to interpret view on the screen and autotuning sonar means less time pressing buttons and more time fishing!
The large 9 inch screen is great for displaying sonar modes beside chart modes so that you can navigate and find fish/structure all from one screen. The screen is backlit and offers increased contrast with the choice of different colour palettes for better viewing in a range of conditions. The IPS screen offers excellent viewability from all angles, even when wearing polarised glasses. These are a vast improvement over older LCD displays that would be tricky to view in some scenarios.
The Eagle 9 features a full GPS chartplotter mode. This allows you to plot marks, draw tracks and create routes so that you can navigate to and from your favourite fishing spots more easily. Navigate to and from your launch spot with ease, and clearly see your vessel speed and heading too. Pre-loaded with a basic worldwide basemap, you can add high detail contour charts by plugging in a Navionics+ Chart Card to the micro SD card slot found on the side of the unit. Alternatively, make use of the Genesis Live feature, where you can create custom ½-foot contour maps as you navigate the water - this draws a map of everywhere your vessel has been allowing to build up your own charts from the sonar readings.
Twist-Lock connectors on the rear of the Lowrance Eagle 9 ensure easy installation and removal of transducer and power leads from the unit. The supplied adjustable base mount can be installed to any flat surface that has sufficient space, or choose an aftermarket Railblaza or Ram Mount with further track and rail mounting options available.
Transducer Options
Lowrance 50/200 HDI Transducer
Choose the Lowrance 50/200 Hybrid Dual Imaging (HDI) transducer to get low-high CHIRP sonar and Downscan Imaging. Low-High CHIRP sonar is great for showing any fish in the water column below you with excellent deepwater performance. Downscan Imaging offers high resolution scanning to show the the bottom structure in excellent detail. Together you can find those shoals of fish, or fish-holding structure more easily! This is the most popular transducer option for kayak and boat anglers fishing coastal waters.
Lowrance Tripleshot HD Transducer
Providing CHIRP sonar, Downscan Imaging and Side Scanning Sonar all in one transducer! Side Scan allows you to see either side of your craft, perfect for spotting those bait shoals or fish holding structures around you. Side Scan works best in shallower lakes, estuaries and coastal areas, with diminishing effectiveness as the depth increases. Please Note: Side Scan Transducers must be mounted in contact with the water and below the keel line of your craft so that the sonar can can shoot either side of the hull.
Sonar Modes
CHIRP Sonar
CHIRP sonar provides high resolution views of fish and other objects within the water column. Great for showing shoals of fish and individual larger fish!
Downscan Imaging
Downscan Imaging uses high frequency pulses of sonar to show high resolution detail of the sea/lake bed and other structures. Great for feature finding!
Side Scan Imaging
Only available with the Tripleshot HD Transducer. Side Scan makes it easier to locate fish holding structure either side of your craft so that you can find those fish even faster! Scan Scan can work up to 600ft either side of your vessel.
Need a visor for your fish finder? Reduce sun glare and spray build-up with a screen visor! We sell the BerleyPro Visor for the Lowrance Eagle 9 Fish Finder? - Click Here to find out more.
Key Features
- Choose from 50/200 HDI LOW/HIGH Transducer or Tripleshot HD Transducer options
- Autotuning Sonar
- FishReveal technology for easier interpretation of sonar readings
- 7in colour IPS Screen - viewable from all angles even with polarised glasses
- Increase contrast and viewability with all-new color palettes
- Worldwide Basemap
- Micro SD Card Slot
- Twist-Lock Connectors
- Typical Power Consumption: 640 mA @ 12 V DC with backlight on full
- Waterproof Rating: IPX7 with card door closed
- One-Year Warranty
Whats Included In The Box?
- Eagle 9 Unit
- Eagle Quick Release Bracket
- 50/200 HDI Transducer & Power Cable
- Transducer Transom Bracket
- Fuse & Fuse Holder
- Instructions
If you need to know what else If you need to install a Fish Finder to your kayak, please refer to our Fish Finder Buyers Guide
Mounting Options - Fish Finder Screen
Ram Mounts 1.5in Ball Universal Fishfinder Mount
This mount will neatly hold larger screen fish finders. Infinite angle adjustment with Ram Mounts ball and socket technology. Includes a 2.5in round base for flat surface mounting. Add a Ram Mounts 1.5in Quick Release Track Base for slide track mounting. M5 bolts are required to fit the a fish finder cradle base to this mount (sold seperately).
Price £51.29 (RRP £56.99 - Saving £5.70)
Railblaza R-Lock R Fish Finder Mount
Easily mount a large screen fish finders with the Railblaza R-Lock R mount. This mount features lockable friction joints and a centre joint that is fully adjustable in 15-degree increments, meaning that you can position your fish finder at the angle you want. Will hold a fish finder upto 1.5kg in weight. Simply mount onto any Railblaza StarPort base mount for surface mounting, or Railblaza TracLoader Starport for track mounting. M5 bolts are required to fit the a fish finder cradle base to this mount (sold seperately).
Price £29.71 (RRP £34.95 - Saving £5.24)
Railblaza Rotating Platform R Fish Finder Mount
A platform design to mount larger fish finder cradle mount. Frcition swivel joint allows 360 rotation. Will hold a fish finder upto 1.5kg in weight. Simply mount onto any Railblaza StarPort base mount for surface mounting, or Railblaza TracLoader Starport for track mounting. M5 bolts are required to fit the a fish finder cradle base to this mount (sold seperately).
Price £15.26 (RRP £17.95 - Saving £2.69)
Transducer Installation Options
If you would like more info on installing a transducer to your kayak, please refer to our Fish Finder Buyers Guide
In-Hull Installation
Please Note: This method is not suitable for side scan transducers.
Sikaflex EBT+ Clear - Transducer Adhesive
A strong and flexible waterproof adhesive. Ideal for glueing a fish finder transducer to the hull of a kayak. Also useful as a sealent when installing other accessories. Supplied as a 300ml cartridge tube.
Price £11.95
Scanstrut Deck Seal - Cable Gland - Upto 30mm
A Cable Gland is the best option for routing the transducer cabling from the Fish Finder headunit down in through the kayak hull. This is the correct sized cable gland for the Lowrance Transducer Cabling. It can also be used for routing the battery cables inside the hull.
Price £29.70
Arm-Mounted Installation
RAM Transducer Arm with Diamond Base
Compatible with both Lowrance and Humminbird Transducers, this arm allows you to hang your transducer directly over the side of your kayak and into the water. This makes for a quick release mounting system.
Price £55.99
Railblaza Transducer Arm XL - 700mm
The Transducer Arm XL is an easy way to mount your fish finder transducer. Simply bolt the transducer to the bottom of the arm and mount the arm to your kayak! NOTE: This kit requires a Sideport to mount the transducer arm. These can either be fixed straight to the hull of the kayak using the fixings supplied with the ports, or they can be mounted on slide tracks, as shown in the images above, using the appropriate TracMount Kit.
Price £39.06 (RRP £45.95 - Saving £6.89)
Fish Finder - Power Options
12v 14ah SLA - Fish Finder Battery
Ideal for powering your Fish Finder. A 12V 14aH SLA battery provides enough charge for a typical day session for 7-9in screen fish finders. Once the battery charge has been run down it needs to be recharged and this is best done using a 12V trickle charger.
Price £41.40 (RRP £46.00 - Saving £4.60)
Feelfree 5 Litre Dry Tube - Battery Bag
A great option for dry storing your Fish Finder battery inside the hull of your kayak. This power cables can easily roll down with the top of the dry bag, whilst still making a dry seal.
Price £11.96 (RRP £15.95 - Saving £3.99)
Scanstrut Deck Seal - Cable Gland - Upto 16mm
A Cable Gland is the best option for routing the power cabling from your Fish Finder Headunit in through the hull and to your battery. This is the correct size for just the battery cable to pass through.
Price £29.70
If you would like more info on powering your Fish Finder, please refer to our Fish Finder Buyers Guide
Delivery
Nationwide delivery available for the Lowrance Eagle 9 Fish Finder. Delivery price will be shown in the shopping basket prior to checkout. For full details on delivery please see: Delivery Information
Click & Collect - Stores Nationwide
Nationwide Click & Collect available for the Lowrance Eagle 9 Fish Finder. Collection for orders placed online can be made from any of our Canoe Shops UK Stores. For full details on our Click & Collect service, please see: Nationwide Click & Collect
